Product introduction

Item name:Molybdenum wire
Material:molybdenum
Standard:GB/T 4182-2003
Packaging:Plywood wooden case
Application:Indystry
Brand name:XIAMET
Place Of origin:China
Inquiry us:sales@sxxinheng.com
Product details

wire cut moly wire

Diameter 0.18mm, large quantity ready stock usually
1. Grade: Mo1,Mo2,TZM,MOLa,WMo

2. Purity : > =99.95%

3. Characteristic:

Melting Point:2610 Degrees Celsius

Boiling Point:5560 Degrees Celsius

Density: 19.3g/cm3

High quality, workability

4. Certificate: ISO9001:2008

5. Product Feature: High melting point, High-density, high temperature oxidation resistance, long service life,

resistance to corrosion..

6. Dimensions and tolerance(According to clients’ requirements):

Grade

Mo-1

Grade

Mo-1

The impurity content is not more than %

       Pb

--

The impurity content is not more than %

Si

0.003

       Bi

--

Ca

0.002

       Sn

--

Mg

0.002

       Sb

--

P

0.001

       Cd

--

C

0.020

       Fe

0.006

O

0.003

       Ni

0.003

N

0.003

       Al

0.002

--

--

 Sizes and detail

Diameter(μm)

Weight/200mmmg

Weight/200mm tolerance

Diameter tolerance %

30≤d≤40

1.47 -2.61

±3.0

----

40

>2.61 – 16.33

±3.0

7.0

100

>16.33 – 256.2

±3.0

----

400

----

----

±2.5

600

-----

-----

±2.0

7. Application:

Molybdenum wire is widely used in lighting (such as used as mandrel, support wire, lead-in wire, etc.), heating components,

 heating material in furnace, wire-cutting, spraying wire, glass to metal seals, printer pins, coil-mandrels,hooks for ordinary lights,

grids for electronic tubes and heaters for hi-temperature furnaces; also hi-temperature structural for halogen lamps, heaters for

 hi-temperature furnace, rotation axis for X-ray and other fields and so on.
